0026W - Timecode
v1.0
published
0026W
v1.0
TIMECODE
Presence, Validity, Continuity
EBU R 122, SMPTE ST 385, ...
Expected TC Values
Expected/Unexpected Values
https://qc.ebu.io/items/0026W/versions/1-0-0/
Check
Report
Summary
- EBU QC Id
- 0026W
- Name
- Timecode
- Status
- published
- Category
- absolute
- Lead editor
- Friedrich Gierlinger
- Aliases
- Tags
- timecode
Versions
| Version | Status | Edition date | Saved by | Note |
|---|
Details
- Definition
- System shall check the available timecode(s) as defined by the the wrapper specifications.
In case of MXF it can be located in the Material Package, Source Package and System item.
The following is to be checked for:
1 - At least 1 timecode source must be present;
2 - TC start value matches user input;
3 - TC discontinuities;
4 - TC is invalid (e.g. seconds=80). - References
-
-
SMPTE ST 385
-
User profiles (e.g. ARD-ZDF)
- Examples
-
-
Timecode track is present in the Material Package start value: 00:00:00:00, in SDTI track start value 00:10:00:002. Timecode start value does not match the provided one: Time code value is 00:00:00:003. Timecode discontinuity detected (00:03:24:03 jumps to 02:03:30:20 at frame number 10)4. Invalid Timecode value detected 79:00:10:00 at frame number 10
-
Input parameters
| Name | Description |
|---|
Output parameters
| Name | Description |
|---|
Test material
| Title | Version | Download |
|---|
Remarks
- Remarks
