0069W - Display Aspect Ratio
v3.0
published
0069W
v3.0
DISPLAY ASPECT RATIO
Display Width:Height
Broadcaster Guidelines
Matches Guidelines
Expected/Unexpected Values
https://qc.ebu.io/items/0069W/versions/3-0-0/
Check
Report
Summary
- EBU QC Id
- 0069W
- Name
- Display Aspect Ratio
- Status
- published
- Category
- absolute
- Lead editor
- Jerome MARTINEZ
- Aliases
- aspect ratio video aspect ratio
- Tags
- video MXF
Versions
| Version | Status | Edition date | Saved by | Note |
|---|
Details
- Description
- Display Aspect Ratio or DAR is the aspect ratio of the intended display device or screen window.
- Definition
- Used in Checks, the system shall read-out the Display Aspect Ratio indicated in the wrapper metadata and check if it matches the expected one specified in the input. Optionally the system may report the Display Aspect Ratio value.
Used in Reports, the system shall read out the Display Aspect Ratio indicated in the wrapper metadata and report it. - References
-
- Examples
-
-
Input: "Display Aspect Ratio Expected" = 4:3
Output: "Check Result" = false
Output: "Display Aspect Ratio" = 16:9Remark: Used as a Check
-
Input: "Display Aspect Ratio Expected" = 4:3
Output: "Check Result" = false
Output: "Display Aspect Ratio" = 0:0Remark: Used as a Check
-
Input: None
Output: "Display Aspect Ratio" = 16:9Remark: Used as a Report
-
Input parameters
| Name | Default value | Description | Data model name | Unit | Locator |
|---|
Output parameters
| Name | Alias | Description | Data model name | Unit | Locator |
|---|
Test material
| Title | Version | Download |
|---|
Remarks
- Remarks
-
For MXF: this metadata element is best effort metadata. If the detected value is a Distinguished Value, the search shall be continued until a non-Distinguished Value is found. If no non-Distinguished Value is found, the Distinguished Value shall be used.
Related SMPTE label: 060e2b34.01010101.04010101.01000000
